Horizontal EPS Styrofoam Foam CNC Cutting Machine

Our factory produces high-quality Horizontal EPS Styrofoam Foam CNC Cutting Machines for precise and efficient fabrication. Get yours today!
Request a Quote

PRODUCTS DETAILS

Basic Info.

Model NO.
CNC--400
Certification
CE, ISO9001:2008
Block Size
Can Be Customized
Voltage
Can Be Customized
Transport Package
Standard Export Package
Trademark
Dongshen
Origin
Zhejiang, China(Mainland)
HS Code
8477800000
Production Capacity
30 Units Per Month

Product Description

CNC cutting machine is to cut EPS blocks to required shapes as per designed drawing. Machine is controlled by PC.

Features:
1.All the machines are driven by the remarkable software:the software speeds up the design process and enables the operator to obtain the best yield from the foam block;
2.It has perfect safe system to prevent the accident:all Motors will stop when the safety dooropened; Exigency button on both machine and control box is for preventing accident.


Model DTC-E2012 DTC-3012 DTC-3030
Max. Product Size L2000*W1300*H1000mm L3000*W1300*1300mm L3000*W3000*H1300mm
Cutting line diameter 0.8~1.2mm 0.8~1.2mm 0.8~1.2mm
Cutting Speed 0~2m/min 0~2m/min 0~2m/min
Cutting System Industrial Computer Industrial Computer Industrial Computer
Computer Operation System Windows XP/Win7 Windows XP/Win7 Windows XP/Win7
Cooling System Air blower Air blower Air blower
Acceptable File Formats DXF/DWG DXF/DWG DXF/DWG
X-Axis Motor Servo Motor Servo Motor Servo Motor
Y-Axis Motor Stepper Motor Stepper Motor Stepper Motor
Number of Cutting Wire up to 20 up to 20 up to 20
Total Power 13.5kw, 380V, 50Hz, 3PH 13.5kw, 380V, 50Hz, 3PH 13.5kw, 380V, 50Hz, 3PH
Gross Weight 1200kg 1500kg 2000kg
Horizontal EPS Styrofoam Foam CNC Cutting Machine
Horizontal EPS Styrofoam Foam CNC Cutting Machine
Horizontal EPS Styrofoam Foam CNC Cutting Machine
Horizontal EPS Styrofoam Foam CNC Cutting Machine
Horizontal EPS Styrofoam Foam CNC Cutting Machine
Horizontal EPS Styrofoam Foam CNC Cutting Machine
