High Accuracy Honeycomb Paper / Corrugated Paper CNC Cutting Machine

Get precise cuts with our High Accuracy Honeycomb Paper / Corrugated Paper CNC Cutting Machine. As a factory, we guarantee quality and efficiency.
Request a Quote

PRODUCTS DETAILS

Basic Info.

Model NO.
YC-1625L
Condition
New
Knife Tool Type
Oscillating Cutting Tool
Safety Device
Infrared Adopted; Sensitive Response; Safe and Rel
Motor
Panasonic Servo 11kw
Voltage
220V/380V 50Hz
Cutting Tolerance
0.1mm
Maximum Cutting Speed
1200mm/S
Translational Velocity
1500mm/S
Cutting Thickness
0.1-20 mm (Subject to Material)
Fixed Mode
Vacuum Absorb
Drive System
Hiwin Linear Rail; Panasonic Motor
Transmission Interface
Ethernet
Transport Package
Wooden Case
Specification
2500*1600mm
Trademark
Yuchen
Origin
China (Mainland)
Production Capacity
50 Pieces / Month

Product Description

High accuracy Honeycomb Paper / Corrugated paper Knife CNC Cutting Machine YC-1625L
High Accuracy Honeycomb Paper / Corrugated Paper CNC Cutting Machine

Model: YC-1625L         Machine size can be customized

Applicable cutting materials: knitted material, tatting material, fur, PU leather, jean demin,  canvas,  foam, artificial leather, diablement fort, blend fabrics,Cotton & Linen, etc

Application: widely used in garment,  bag, belts, footwear, shoes insole, wallets and leatherwear industriy and so on.
Functions: cutting, punching , drawing.
Standard Equipments: oscillating knife Driven rotary  punching tool universal cutting tools

Parameter:

Model

YC-1625L

YC-1630L

YC-1625A

Working area

2500×1600mm

3000×1600mm

2500×1600mm

Operation properties

continuous cutting with high efficiency, 7*24 with zero downtime

Safety device

Infrared sensor; sensitive response; safe and reliable

Maxi cutting speed

1200mm/s

Translational velocity

1500mm/s

Applicable materials

KT board, Corrugated cardboard, EPE, PVC, acrylic, thick foam, etc

Multifunctional head

Oscillating cutting tool, Rotary cutting tool,

Punching cutting tool, Drawing tool

Cutting thickness

0.1-20mm (subject to material)

0.1-10.0mm (subject to the material cutting)

Cutting tolerance

±0.1mm

Transmission interface

Ethernet

Driven system

Motor: Panasonic

Linear rail: Hiwin

Fixed mode

Vacuum absorb

Supply voltage

220V 380V±10%,50HZ

AC 220V 380V±10%,50HZ

Rated power

11KW
